GENUINELY TOUGH AND CAPABLE
The IVECO Astra starts tough from the ground up, with a strong, high tensile steel C-Section chassis reinforced with cross members. With its flat chassis rails, the Astra is suitable for fitment of a wide range of bodies, with minimum need for modification.
The Astra features permanent all-wheel drive to all 8 axles and is fitted with parabolic front leaf springs and rear IVECO cantilever springs providing excellent load carrying ability, comfort and off-road performance. The suspension features a standard stabiliser bar on the 1st and 4th axles.
Utilitarian and no-nonsense from the outside, inside, the Astra cabin boasts many of the comfort and ergonomic features IVECO delivers in its road-going models. Unique design features allow for the heavy duty tasks the Astra is built for including air suspended driver’s seat, 4-speed ventilation and heating with air recirculation, compressed air ‘quick coupling’ for cab cleaning, and washable and fire-proof internal cab panels.
- Spring suspended cabin for extra comfort.
- Tinted electric windows.
- 4-speed ventilation and heating system with air recirculation.
- Detailed multifunction display and instrument cluster.
- Ergonomically designed dashboard.
- 3-way adjustable air suspended driver's seat.
- Compressed air ‘quick coupling’
- Washable and fire-proof internal panels
OPTIONS FOR EVERY APPLICATION
IVECO pairs the Astra’s Cursor 13 engine with a ZF Eurotronic II automated transmission for maximum control. The ZF Eurotronic II is a 16 speed transmission with electronically controlled clutch engagement. While driving in automated mode, the Eurotronic transmission automatically selects the most ideal gearshift according to such inputs as load, road speed and road incline. It also offers the flexibility to manually select gears should the application and track conditions require.
As an alternative, if your specific application requires a full automatic transmission, owners can select the optional Allison 4700 transmission.
REPORTING FOR HEAVY DUTY
The Astra 8x8 is IVECO’s largest and most heavy-duty off-road vehicle available in the range, delivering the power, performance and productivity IVECO is renowned for. It’s purpose-built to tackle the most demanding off-road applications.
The Astra features huge ground clearance, a full-time 8x8 system with lockable diffs on all axles and a choice of two powerful horsepower options, making it a true off-road specialist.
Amongst many applications requiring a heavy-duty vehicle, the Astra is ideal for use in mining, exploration, drilling, forestry and water haulage.
A TRUE WORKHORSE
Boasting the traction of an all-wheel drive 8x8 driveline, IVECO parabolic front suspension, IVECO cantilever rear suspension and the well-regarded IVECO Cursor 13 engine available in 480 or 520hp outputs, the Astra delivers powerful performance that makes light work of the toughest conditions.
The Astra is equipped with differential locks and hub reduction on all axles, and with its 48 tonne GVM and 70 tonne GCM, is capable of handling the largest of loads. Fitted with the ZF Eurotronic II 16-speed automated transmission, the Astra is also available with the optional Allison 4700 full automatic.
ASTRA QUICK SPECS
|ENGINE||Cursor 13 Litre Enro 5 (rear engine PTO option)|
|POWER / TORQUE||480HP / 2300NM and 520HP / 2400NM|
ZF 16-Speed manual
Optional Allison 4700 automatic
|REAR AXLE RATIO||5.009 : 1 (additional options available)|
Front: Parabolic leaf springs plus airbag (load sharing)
Rear: IVECO cantilever
|GVM / GCM||48 tonnes / 70 tonnes|
|FUEL CAPACITY||300L (optional 600L)|
|ADBLUE||1 X 45L|
POWER AND TORQUE
The Astra is powered by IVECO’s Cursor 13, 6 cylinder turbocharged diesel engine, with the engine available in two sets of tune. Both engines provide strong power and torque from low in the rev range, ensuring the trucks can handle the demands of the most difficult applications.
Meeting Euro 5/ADR 80-03 emission standards, the Cursor 13 engine is fitted with Selective Catalytic Reduction (SCR) technology which reduces the level of toxic gases emitted from the engine and provides a significant decrease in fuel consumption.
- Engine available in two sets of tune - 480 hp/2300 Nm or 520 hp/2400 Nm.
- Engine fitted with Selective Catalytic Reduction (SCR) technology to reduce emissions.
- Paired with ZF Eurotronic II 16-speed automated transmission.
